Laser SLAM Pallet Jack Robot JCJV-CSK15-XW

1.5-Ton Payload Capacity | Industry-Leading Cost Efficiency

• Rated Load Capacity: 1500 kg
• Comprehensive Runtime: 8 h
• Rotation Diameter: 1264 mm
• Number of LiDARs: 2 (Model H1)
• Positioning Accuracy: ±5 mm, ±0.5°
• Max. Travel Speed: ≤1.5 m/s
• Dimensions (L x W x H): 1224 x 861 x 260 mm
• Chassis Ground Clearance: 25 mm
• Lifting Platform Dimensions: 1060 x 720 mm
• Max. Lifting Stroke: 60±2 mm
Wholesale Inquiry

PRODUCT DETAILS

[ 1500 kg Lifting Vehicle Series, Ultimate Cost-Effectiveness ]
Based on partners within the XianGong ecosystem, the overall BOM cost of the vehicle has been minimized; the 1.5-ton lifting L series and the following lifting K series are the first choice for flexible transfer of large-tonnage goods.

[ Hybrid Navigation, ±5 mm Accuracy ]
Supports SLAM, QR code, reflector, and 2D NFL navigation, and can match the corresponding navigation solution according to the needs of the scenario; achieving ±5 mm repeatability accuracy, enabling precise handling of goods between designated locations, efficient and flexible.

[ Dual Laser + 3D Camera, Enhanced Safety ]
Front and rear dual laser configuration, bidirectional path protection; the front can be equipped with an optional 3D camera component for pothole and obstacle detection, ensuring safe movement; front and rear contact collision strips provide immediate stop upon contact, ensuring worry-free safety.

[ 10 Minutes of Charging, 1 Hour of Operation ]
A 10-minute charge ensures 1 hour of vehicle operation; a 60-minute fast charge provides 70% full charge, and 8 hours of worry-free driving.
