Laser SLAM Pallet Jack Robot JCJV-CSK10-BH

1-Ton Lift Truck Series: Optimized Performance & Value

• Rated Load Capacity: 1000 kg
• Comprehensive Runtime: 8 h
• Rotation Diameter: 1220 mm
• LiDAR Configuration: 1 x H1 Model + 1 x C2 Model
• Positioning Accuracy: ±5 mm, ±0.5°
• Max. Travel Speed: ≤1.5 m/s
• Dimensions (L x W x H): 1150 × 800 × 250 mm
• Chassis Ground Clearance: 20 mm
• Lifting Platform Dimensions: 1030 × 770 mm
• Max. Lifting Stroke: 60 ± 2 mm
Wholesale Inquiry

PRODUCT DETAILS

[ Exceptional Cost-Effectiveness, 1T Lifting Series: The Top Choice ]
Based on ecosystem partners, the overall BOM cost of the vehicle has been minimized. The overall size is comparable to standard products of the same type, making it the best choice for transporting 1000kg-class materials.

[ Hybrid Navigation, ±5mm Accuracy ]
Supports SLAM, QR code, reflector, and 2D NFL navigation, allowing for customized navigation solutions based on scenario requirements. Achieving ±5mm repeatability accuracy, it enables precise and efficient handling of goods between designated locations.

[ Dual Laser + 3D Camera, Enhanced Safety ]
Front and rear dual laser configuration provides bidirectional safety. An optional 3D camera component at the front detects potholes and obstacles, ensuring safe movement. Front and rear contact-type collision strips provide immediate stop upon impact, ensuring peace of mind.

[ 10 Minutes of Charging, 1 Hour of Operation ]
A 10-minute charge provides 1 hour of operation; a 60-minute fast charge reaches 70% charge, providing 8 hours of worry-free driving.
